◆Advanced apochromatic technology and unique optical balanced technology effectively improves the binocular visual fusions, strengthenes in third dimension and reduces surgeon’s tireness during operations.
◆Fine focusing knob is under the bottom of assistant binocular. The observation of the assistant’s microscope can be finely focused independently of the main microscope to avoid different observation from surgeons.
◆20° oblique illumination can also be used as slit illumination. Slit width is continuously adjustable.
Specifications
Eyepiece Magnification
12.5×, 18×
Diopter Adjustment
±7D
Magnification for Main Microscope
4×, 6×, 10×, 16×, 25×
Magnification for Assistant Microscope
6×, 10×, 14×
Focal Length of Objective Lens
f=200 mm
Diameter of View Field
58 mm, 38 mm, 23 mm, 14 mm, 9mm
Pupilary Adjustment
50 mm ～ 75 mm
Maximum Resolution
119 LP/mm
Working Distance
190 mm
Focusing Range for Assistant Microscope
≥30 mm
Light Source
12V/10W, medical cold reflection halogen lamp
Illumination Type
6°+0° coaxial illumination, 20° oblique illumination(can be used as silt illumination with slit width adjustable)
