PARAMETER

SPECIFICATION

Drug library

10 categories of drugs, amounts to 1030 kinds of drug names, 17kinds of dose unit, such as ug/kg/min, mg/kg/min, etc.

Makes drug dispensing more convenient and safer.)

History record function

Record infusion start time, infusion over time, infusion rate, alarms, drug name, dose and bolus volume, etc.

Drop Detector

Outside caliper rotary detector (patent) Infrared sensor

Control Way

Drop counting and adjusting the delivery rate automatically

Fit IV tubes

20d/ml,60d/ml and other, as well as brown tubes

Pump Type

Peristaltic finger pump

Accuracy

±2%, when delivery rate ≤25drop/min (drop counting & time control mode)

±3%, when delivery rate >25drop/min (drop counting & time control mode)
±5% (Volume control mode after the correct calibration)

Delivery rate range

0.1ml/h～1200ml/h (0.1ml/h～99.9ml/h, 0.1ml/h step; >99.9ml/h, 1ml/h step)

Delivery time range

1min～1999min (1 min step)

Volume limit range:

0.1-9999ml (0.1~99.9ml, 0.1ml step, above 100ml, 1 ml step)

Total Volume Range

0.1-9999.9ml (0.1~99.9ml, 0.1ml step, above 100ml, 1 ml step)

Purge Rate

600.0ml/h

KVO Rate

KVO is 1ml/h when the delivery rate≤10ml/h, Otherwise KVO is 3ml/h.

Occlusion pressure

Three level setting LOW, MEDIUM or HIGH

Alarms

Near empty, Syringe empty, Volume complete (when limit volume is set), Occlusion, Syringe loose, Operation error, Low battery, device failures.

Three levels of alarm volume LOW, MEDIUM or HIGH

Bolus function

Bolus rate:10 ~1200ml/h (pre-selected), Bolus volume: maximum of 100ml

Power source

AC power supply: AC 100 to 240V (+/-10%), 50/60Hz; Built-in Lithium Battery: Rechargeable, 11.1V, 2000mAh. 6 hours of continuous operation

Accessories:

AC power line, Operational manual

Interface

RS-232 or USB

Protection Class

Class I, Type CF,IPX4

Dimension /Net weight

130mm*230mm*130mm,2.5kg
